• 100% automated positioning Faster, more accurate, fewer errors • Up to 60 components per minute • Cuts floor truss webs 3x2; 4x2; 6x2 • Square (90/90) webs From 7-7/8 in to 45-1/2 in • Angled webs 15775°-75715° 10-1/4 in to 48 in • Saw files read; EHX, TRS. Sapphire XML. EZY, CYB, WCD. AS1. BTL. BTLx, Alpine eShop • Five (5) 4.5 KW (6 HP - 460 V - 3 ph) blade motors with integrated mechanical brakes 14 in blade • Totally enclosed frame Less noise, less dust • 27 flights infeed chain • 10-piece manual feeder • Machine configuration backup system for seamless recovery/ restart • Real-time statistics compilation and error tracking, accessible via our customer portal • cULus approved control panel • Intuitive multilingual HMI in English, French and Spanish

• Sealed bearings used to minimize maintenance time and increase lifetime • State-of-the-art control panel featuring Schneider Electric PocDrive 3 electronics • Five (5) high resolution, high speed, high torque Schneider Electric LXM62 1LM series integrated AC servomotors for accurate positioning • Hybrid cable plug and go technology for easy replacement • Planetary gearboxes with lifetime lubrificotion for increased efficiency and minimal maintenance • Easy axis-by-axis calibration • Automatic, semi-automatic & hybrid manual mode • 24 in Lenovo touchscreen SSD computer with Windows 1 1 Pro operating system and asiW software featuring an ultra-intuitive HMI • Lifetime access to software updates
