WFTP-1226, Trackless Floor Truss Machine, Features: • 10 hp, 3 phase, 208/230/460/575VAC, 60Hz breaking gear motor • 3/4” steel table top • Truss depths from 12” to 26” • 7' wide, 24" x 1" Roll • Emergency shut-off bars on both sides of the press head • Joystick Operation Control • 2' per second travel speed • 7' wide x 40' long work surface table • Truss flip-over arms • End Eject Pop-Up Rollers or Side Eject • All air cylinders under table • 2 Flat Park-Stations 5’ x 7’ • 2 control valves for clamping on either side of table • 1 control valve for Pop-Up Rollers or Side Eject • 1 control valve for flip-over arms • Built in camber for clamping on both sides

Optional Floor Truss Stacker Features: • 2 hp, 3 phase, 208/230/460/575VAC, 60Hz breaking gear motor • Truss stands with index heads • Lifting arms and 15/30 truss capacity • Manual & automatic electrical controls • Adjustable crash bar • Single Truss and Double (2 high) Truss mode • Powered outside conveyor • 3½" dia. conveyor rolls 4' O/C
